Warehouse containers have the characteristics of convenient movement, low pollution, design and production of different specifications (referring to the size of unit space) according to the needs of different users and repeated use. After scrapping, they can also be recycled as waste steel, so they are widely welcomed.

2結構特點

2. Structural features

倉庫式集裝箱按照標準集裝箱的外形尺寸設計生產,根據用戶要求分隔成不同數量的空間,1個20英尺集裝箱可分隔為12個單位空間,每個空間的大小約為3。

Warehouse containers are designed and produced according to the overall dimensions of standard containers. They are divided into different quantities of spaces according to user requirements. A 20 foot container can be divided into 12 unit spaces, and the size of each space is about 3.

地震多發國和地區對倉庫式集裝箱有抗震要求,故主體柜架采用型鋼設計,四角立柱采用4.0(4.5)mm×150 mm×150 mm方管,其他側梁采用4.0 mm×100 mm×150 mm方管。四角立柱的端板采用或以上厚度的厚板,其中間孔按標準集裝箱角件孔的位置及尺寸進行設計。端板帶有手柄,手柄上可配鉆2個直徑不小于的孔。在堆放23層集裝箱時,此孔可用于集裝箱與地面及上下層集裝箱之間的連接,連接方式比較簡單,立柱側面上下各設計2個與標準角件位置及尺寸相同的孔。

Earthquake prone countries and regions have seismic requirements for warehouse containers, so the main cabinet frame adopts section steel design, and the four corner columns adopt 4.0 (4.5) mm × 150 mm × 150 mm square pipe, 4.0 mm for other side beams × 100 mm × 150 mm square pipe. The end plate of the four corner column shall be a thick plate with a thickness of or above, and the intermediate hole shall be designed according to the position and size of the corner hole of the standard container. The end plate is equipped with a handle, which can be equipped with two holes with a diameter of no less than. When stacking 2-3 layers of containers, this hole can be used for the connection between the container and the ground and the upper and lower containers. The connection method is relatively simple. Two holes with the same position and size as the standard corner pieces are designed at the upper and lower sides of the column.

倉庫式集裝箱的箱門可分為卷簾門、帶門桿門封膠條式鐵門、防盜門等不同型式?？紤]到風力較大時卷簾門可能發出較大的噪聲,可選用靜音卷簾門,即在卷簾導軌內側加裝膠條,從而減小噪聲。

The door of warehouse container can be divided into rolling shutter door, door sealing rubber strip iron door with door rod, anti-theft door and so on. Considering that the rolling shutter door may make a large noise when the wind is strong, the silent rolling shutter door can be selected, that is, a rubber strip is installed on the inner side of the rolling shutter guide rail to reduce the noise.

倉庫式集裝箱一般不承受重載,故可采用厚的木地板,頂板、側板及端板等可采用厚的鋼板,門間立柱可采用或以下厚度的鋼板,底橫梁可選用3.0厚的鋼板,從而減少材料成本。

Warehouse containers generally do not bear heavy loads, so thick wooden floors can be used, thick steel plates can be used for top plate, side plate and end plate, steel plates with or less thickness can be used for columns between doors, and 3.0 thick steel plates can be used for bottom beams, so as to reduce material costs.
